7.3 Insert call data variables into the URL

Variables carry call data to the receiving system inside the URL.

• In the connection form, place the cursor in the URL field where the value belongs.
• Seleccione Add variables.
• Seleccione the variable you need. It is inserted into the URL at that position.
• Repeat for each value the receiving application requires.
• Check the complete URL against the receiving application's documented format before you save.

Available variables, ten in total:

Variable	Token
Llamadaer Números	{callerNúmeros}
Agente ID	{agentId}
Queue ID	{queueId}
Org ID	{orgId}
App ID	{appId}
First Nombre	{first_name}
Last Nombre	{last_name}
Teléfono Números	{phone_number}
Email	{email}
Estado	{status}

Always insert tokens with Add variables rather than typing them - Every token uses single braces, as shown above. Typing a token by hand risks a spelling or brace error that the form will accept and that then fails silently at call time, because a malformed token is sent to your endpoint as literal text rather than as a value. Add variables inserts the correct form every time.

If you inherit a connection whose URL uses double braces, for example {{phone_number}}, do not copy that pattern into a new connection. Rebuild the URL using Add variables, and raise the existing record with support@ncsapp.com so it can be checked.

Figure key, Add variables picker

• URL field, with the insertion point.
• Add variables control.
• Variable picker panel.
• The ten variables with their tokens: Llamadaer Números {callerNúmeros}, Agente ID {agentId}, Queue ID {queueId}, Org ID {orgId}, App ID {appId}, First Nombre {first_name}, Last Nombre {last_name}, Teléfono Números {phone_number}, Email {email}, Estado {status}.
• The assembled URL showing the inserted token.
